Оптический трансивер Huawei SFP-10G-USR

Model

Description

S5700-28P-LI-AC

24 x Ethernet 10/100/1000 ports, 4 Gig SFP, AC 110/220V

S5700-28TP-LI-AC

24 x Ethernet 10/100/1000ports,2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP,AC 110/220V

S5700S-52P-LI-AC

48 x Ethernet 10/100/1000 ports, 4 Gig SFP, AC 110/220V

S5700-28P-PWR-LI-AC

24 x Ethernet 10/100/1000 PoE+ ports, 4 Gig SFP, AC 110/220V

S5700-10P-PWR-LI-AC

8 x Ethernet 10/100/1000 PoE+ ports, 2 Gig SFP, AC 110/220V

S5720-36C-EI-AC

28 x Ethernet 10/100/1000 ports,4 of which are dual-purpose 10/100/1000 or SFP,4 10 Gig SFP+,

1 interface slot, with 150W AC

S5700-28C-EI-AC

24 x Ethernet 10/100/1000 ports, with 1 interface slot, with 150W AC power supply

S5720-56C-HI-AC

48 x Ethernet 10/100/1000 ports, 4 10 Gig SFP+, with 2 interface slots, with 600W AC power supply

S5720-56PC-EI-AC

48 x Ethernet 10/100/1000 ports,4 Gig SFP, with 1 interface slot, with 150W AC power supply

S5720-56C-PWR-HI-AC

48 x Ethernet 10/100/1000 POE+ ports,4 10 Gig SFP+, with 2 interface slots, with 1150W AC power supply

Item

SFP-10G-USR

OSX010000

Transceiver form factor

SFP+

SFP+

Transmission speed

10 Gbit/s

10 Gbit/s

Center wavelength (nm)

850

1310

Standard compliance

10Gbase-USR

10Gbase-LR

Connector type

LC

LC

Applicable cable and maximum

transmission distance

Multimode fiber (OM3): 0.1 km

Single-mode fiber: 10 km

Transmit power (dBm)

-7.3 to -1.0

-8.2 to +0.5

Maximum receiver sensitivity (dBm)

-10.7

-12.6

Overload power (dBm)

0.5

0.5

Extinction ratio (dB)

3.0

3.5

Operating temperature

0°C to 70°C (32°F to 158°F)

0°C to 70°C (32°F to 158°F)

Net Dimension(D x W x H mm)

145 x 80 x 35

110 x 70 x 37
